Description
Hardware configuration |
Processor MT7628DA |
Hardware interface |
Two 10/100M self-adaptive LAN ports (Auto MDI/MDIX)One system factory settings reset buttonOne orange/blue/purple system status light; one blue external network interface status lightOne 10/100M self-adaptive WAN port (Auto MDI/MDIX)One power input interface |
Wireless specifications |
single band2.4GHz
Modulation
11b: DSSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)11g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM (24/36Mbps), 64QAM (48/54Mbps)11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0 to MCS15
Reception sensitivity11Mbps: ≤ -85dBm, 54Mbps: ≤ -72dBm, HT20 MCS7: ≤ -69dBm, HT40 MCS7: ≤ -66dBm
|
Software specifications |
Operating systemMi Wi-Fi ROM intelligent router operating system based on a highly customized version of OpenWRT that supports web, Android, and iOS router management software Wireless securityWPA-PSK/WPA2-PSK encryption, wireless access control (blacklist and whitelist), SSID hiding Management application Supports web, iOS, and Android |
Package contents |
User manual Power adapter Mi Router 4C |
Details
SKU : 6970244525529
